Super Slim Design – With super slim indoor unit, the fashionable design brings great visual enjoyment.
Follow Me – The inbuilt thermistor in the remote controller will sense the temperatures surrounding the user, allowing the system to offer the greatest levels of comfort control.
Low Ambient Cooling – With built-in low ambient kit and a specially designed PCB, the outdoor fan speed is automatically changed according to the condensing temperature. Cooling is achievable down to -7°C.
Temperature Compensation – This function helps overcome any discrepancies in temperature that can be found between the height of the indoor fan and controlled space. Helping provide a more accurate temperature control.
360° Air Flow Panel – 360 degree air outlet creates a soft and gentle air flow which circulates throughout the whole space, offering optimum temperature distribution.
Refrigerant Leakage Detect – This function automatically monitors the operating parameters of the system and stops the equipment from running if a refrigerant leak is detected.
Emergency Use Function – If a temperature sensor error occurs the unit will alarm and operate in emergency function mode until replaced. The system will continue to operate based on average readings from the previous days control.
Reserved Air Outlet – Reserves the space for air outlet from the indoor side; It’s available to connect air duct from the four sides to the nearby small rooms.
Fresh Air – Outside air can be ducted onto the indoor fan coil to provide room occupants with fresh and healthy air.
Auto Restart Function – If the system is stopped because of power interruption it will automatically restart in the previous settings and mode when the power resumes.
Louver Position Memory – When you start the unit next time, the angle of horizontal louver will automatically move to the same position as you set last time.
Built-in Drain Pump – The inbuilt drain pump can lift condensing water up to 750mm.
Specification:
The Indoor Unit
Power Options, V/Hz/Ph : 220/50/1
Nominal Capacity, BTU ( kW)
Operating Current, (A)
Heating :6.9 (2.1-11.7) Amp.
Cooling : 8.9 (2.3-10.7) Amp.
Energy Efficiency Ratio
Air flow rate, m3/h : 1850 … 1400
The outdoor Unit
Compressors Type : Full DC Inverter
Refrigeration
Refrigeration Type : R410A
Freon Weight, kg : 4.0, kg
Power Options, V/Hz/Ph : 380~415-3-50
Min length of main line, m : 3
Max length of main line, m : 65
Max vertical drop, m : 30
Weight, kg
Net Weight : 108.00
Note: Installation Charge : Rs 8000
